Harware Projects

Project
Version
Description

Dad Joke Generator

Project Archive


November 2024

There is no better way to annoy your loved ones than blasting them with dad jokes all day. However, you may not always be available to do so when things like your day job get in the way, etc.
But here is the perfect solution to this problem. Just put this somewhere accessible, and whenever someone is in need of paternal annoyance, all they have to do is press the big green button.
This is a simple project running on an Ardunio Nano and a small thermal printer which can be purchased at Amazon, AliExpress, etc. or salvaged out of POS equipment.


For the source code, wiring diagram, STL files, etc, download the project archive, using the link to the left.





Nixie Clock

Project Archive


November 2023

This project uses Amperex ZM1005 nixie tubes salvaged in the 1980s from an old Dana digital benchtop voltmeter. The footprints on the PCB are compatible with ZM1000 and ZM1005 tubes from Amperex, Phillips, etc. However, the circuit should also work any most other Nixie tubes (adjust the booster supply voltage accordingly).
The driver board works with SN74141 or Russian k155id1 (easier to find on eBay) BCD-Decimal drivers. A set of 74HC595 8-bit shift registers (1 per every 2 digits) is used to convert the serial data to BCD.
While any micro-controller board with at least 3 I/Os for the serial interface can control the Nixie driver board, an ESP32 WROOM was chosen for this project to take advantage of WiFi connectivity for SNTP time synchronization. The code uses the WiFiManager library to provide an easy way to set up the WiFi and clock settings.


For, schematics, PCB files, source code, STL files, etc, download the project archive, using the link to the left.





ESP32 GPT ChatBot

Project Archive


April 2023

Reusing the hardware from my Termi3 project below, this adds ChatGPT functionality to the TI Silent 700 terminal (or any other retro terminal or computer with an RS232 port).

This project is written in MicroPython and runs on an ESP32, using the "gpt-3.5-turbo" model of the OpenAI API.


For the source code, download the project archive, using the link to the left.





TTS Speaker

Project Archive


March 2023

This is a simple build that combines a USB to Serial UART adapter with a Text-to-Speech module and an audio amplifier with speakers. For my version, I used an FTDI UBM232R module, an Emic-2, and a cheap Amp/Speaker kit from Amazon.


For a wiring diagram, STL files for the enclosure, etc, download the project archive, using the link to the left.





Termi3

Project Archive


3.0.1
Apr-2023

Termi3 is an update of Cameron Coward's excellent Termi2 project.


Just like Termi2, Termi3 also runs on an ESP32 with MicroPython and reuses much of Cameron's code, with some enhancements such as special character handling, support for back space to fix typos (very important :-)), recovery from a loss of network without needing to reboot, the ability to prompt the user for new WiFi credentials in case the the setup is moved to a different location and the currently configured WiFi network can't be found, and the support for a configuration menu that lets the user change some basic settings.


My project updates the hardware for use with newer TI Silent 700 terminals such as the 703 which can communicate at 1200 baud. It also takes advantage of the TI Silents acoustic coupler port to provide power to the ESP32, thus eliminating the need for an internal battery. Signal level shifting between the TI Silent and the ESP32 is done via a MAX3232 RS232 to TTL level shifter module. The DTR signal from the TI Silent is used to control the EN signal of the ESP32, making it possible to reboot the controller with the "ON LINE" switch of the TI Silent (which can be handy :-)).


I may publish a full-fledged Instructable at some point, but meanwhile, you can download the project archive, which hopefully includes enough information for others to be able to build it, using the link on the left.





TFT Nixie Clock

Project Archive


2021

- Teensy 4.1 microcontroller board
- 1.14 inch 135x240 TFT LCD Display Modules
- ESP8266 Wifi module for NTP time synchronization
- 5V relay for optional click sound





FlipDot Clock

Project Archive


2018

A clock built with a flip-dot display, driven by NCV7719 half-bridge drivers controlled by a Teensy 3.2.

Order PCBs here.





Speaking Cylon Pumpkin

Project Archive


2013

Taking advantage of the versatility of the Emic 2 text-to-speech module, this project creates a fun Halloween prop that is pretty effective in startling trick-or-treaters.


The project archive with the Arduino code, parts list, and wiring instructions can be downloaded using the link on the left.





Arduino Ambilight

Project Archive


2010

A very simple hack using lowpass filters on the VGA color signals and an Arduino that generates PWM from the filtered signals driving an RGB LED strip.


The project archive with the Arduino code and schematics can be downloaded using the link on the left.
